DL9 Hybrid Driving

€219.19
Tax included
HiDrive LED 15 driving light — pair, 15,300 lumens (Cree XPL HI, 8 W per LED) with oversized TIR optics for a long‑range hybrid beam (up to 560 m); DataDim 3‑wire plug‑and‑play dimming; DrySeal waterproof construction; 4 mm steel brackets; UV‑hardened polycarbonate lenses; 6000 K, 9–32 V, 4.5 × 4.5 × 2 in.
Quantity

  Garanties sécurité

(à modifier dans le module "Réassurance")

  Politique de livraison

(à modifier dans le module "Réassurance")

  Politique retours

(à modifier dans le module "Réassurance")

  • HiDrive LEDs 15 — 15,300 lumens per pair: Premium CREE XPL HI LEDs at 8 W each, grouped in a 9‑LED square housing for a powerful, focused beam.
  • Oversized TIR optics: optimized hybrid projection system. Our proprietary TIR optics distribute light far more efficiently than traditional reflectors, delivering exceptional beam distance and width in an ultra-compact package.
  • DataDim™ Plug-&-Play Dimming: 3‑wire design with dedicated dimming wiring, ensuring maximum reliability and plug‑and‑play connection to DENALI, DialDim systems and CANsmart controllers.
  • DrySeal™ — waterproof sealed-beam construction: robotically sealed lens and internal potting at the cable entry to ensure complete waterproofing, even without external connectors.
  • Oversized yet economical design: 4 mm powder-coated steel mounting brackets, robust heatsink for vibration resistance up to 21 grms, and reinforced polycarbonate lenses with hardened UV-resistant coating.
  • Specifications (Unit | Pair):
  • LED: CREE XPL HI (8 W each)
  • Power: 72 W | 144 W
  • Current draw: 6 A | 12 A
  • Raw lumens: 7,650 | 15,300
  • Beam distance: 1,380' (421 m) | 1,835' (560 m)
  • Beam width: 360' (110 m) | 478' (146 m)
  • Connector: 3‑pin DT connector compatible with DataDim
  • Color temperature: 6,000 K
  • Operating voltage: 9–32 VDC
  • Pod dimensions: 4.5" x 4.5" (rectangular) x 2" deep
DENALI
20013002
15 Items

Data sheet

Couleur de l'éclairage/de l'ampoule
Ambre
watts
72 W
Pour marque
Universel
Couleur du verre
Ambre
Couleur de la moulure de finition
Black
Luminosité
7.650 lm
Température de la lumière
6 000 K
Marque
DENALI
Référence fournisseur
DNL.DL9.050.A
Nom du produit
Module d'éclairage hybride
Type
Feu de gabarit
Unités
Pièce
