DL4 Hybrid Driving

€125.25
Tax included
HiDrive 3" × 3" × 2" square projector: Cree XPL HI LEDs (8 W) delivering 6,800 lm per pair; hybrid TIR optics for exceptional range and spread; DataDim 3‑wire plug‑and‑play; sealed DrySeal construction; robust heat dissipation and mounting hardware; ECE‑approved road beam; 6000 K; 9–32 V.
Quantity

  Garanties sécurité

(à modifier dans le module "Réassurance")

  Politique de livraison

(à modifier dans le module "Réassurance")

  Politique retours

(à modifier dans le module "Réassurance")

  • HiDrive LEDs 6 — 6,800 lumens per pair: premium 8 W CREE LEDs each for a powerful beam, housed in a 9-LED square housing.
  • Oversized TIR optics: our patented TIR optics create an optimized hybrid driving beam; they distribute light more efficiently than traditional reflectors to deliver greater throw and width while maintaining a compact housing.
  • DataDim™ Plug-&-Play Dimming: 3-wire design with a dedicated dimming circuit for maximum reliability and plug-and-play connection to DENALI beams, DialDim controls, and CANsmart controllers.
  • DrySeal™ Sealed Beam Construction: robotically sealed lens and internal cable-entry overmold to ensure full waterproofing, even without external connectors.
  • Oversized yet affordable construction: 4 mm powder-coated steel mounts, robust heatsink providing vibration resistance up to 21 grms, and UV-treated polycarbonate lenses for increased durability.
  • ECE-compliant driving beam: the hybrid beam is ECE certified for road-legal use as a primary driving lamp or auxiliary driving lamp within the European Union; yellow or amber lenses are not approved for road-legal use as driving lamps.
  • Specifications (Single | Pair):
  • LED: Cree XPL HI (8 W each)
  • Power: 32 W | 64 W
  • Current draw: 2.7 A | 5.4 A
  • Raw lumens: 3,400 | 6,800
  • Beam distance: 820' (250 m) | 1,091' (333 m)
  • Beam width: 157' (48 m) | 209' (64 m)
  • Connector: 3-pin DT, DataDim™-compatible
  • Color temperature: 6000 K
  • Operating voltage: 9–32 V DC
  • Pod dimensions: 3" x 3" square x 2" deep
DENALI
20012998
5 Items

Data sheet

Couleur de l'éclairage/de l'ampoule
Yellow
watts
32 W
Couleur du verre
Yellow
Couleur de la moulure de finition
Black
Luminosité
3.400 lm
Température de la lumière
6 000 K
Marque
DENALI
Référence fournisseur
DNL.DL4.050.Y
Nom du produit
Module d'éclairage hybride
Type
Feu de gabarit
Unités
Pièce
