Replacement Shim

€10.69
€9.62 Save 10%
Tax included
Replacement discs (outer diameter Ø 7.48 / 8.90 / 9.48 / 10.00 mm) sold individually or in packs of five (for resellers). Available in an assorted box or as economical, easy-to-install refills. Several kits (ref. 0926-1018/1470/0941/1473/0917/1472/0989/1471) include three shims per thickness across ranges of 1.20–3.50 mm or 1.72–2.60 mm, in 0.05 mm / 0.04 mm increments.
Quantity

  Garanties sécurité

(à modifier dans le module "Réassurance")

  Politique de livraison

(à modifier dans le module "Réassurance")

  Politique retours

(à modifier dans le module "Réassurance")

  • Replacement pads with a 7.48 mm diameter.
  • Replacements are sold in packs of five for resellers and individually for retail customers.
  • Available as a fully assorted box or in a five-replacement pack.
  • Cost-effective, easy-to-install replacement solution to substitute expensive original pads.
  • Kit #0926-1018: shims with a 7.48 mm outer diameter, three pieces of each thickness from 1.20 mm to 3.50 mm in 0.05 mm increments.
  • Kit #0926-1470: shims with a 7.48 mm outer diameter, three pieces of each thickness from 1.225 mm to 3.475 mm in 0.05 mm increments.
  • Kit #0926-0941: shims with a 9.48 mm outer diameter, three pieces of each thickness from 1.20 mm to 3.50 mm in 0.05 mm increments.
  • Kit #0926-1473: shims with a 9.48 mm outer diameter, three pieces of each thickness from 1.225 mm to 3.475 mm in 0.05 mm increments.
  • Kit #0926-0917: shims with an 8.90 mm outer diameter, three pieces of each thickness from 1.72 mm to 2.60 mm in 0.04 mm increments.
  • Kit #0926-1472: shims with an 8.90 mm outer diameter, three pieces of each thickness from 1.74 mm to 2.58 mm in 0.04 mm increments.
  • Kit #0926-0989: shims with a 10.00 mm outer diameter, three pieces of each thickness from 1.85 mm to 3.20 mm in 0.05 mm increments.
  • Kit #0926-1471: shims with a 10.00 mm outer diameter, three pieces of each thickness from 1.875 mm to 3.175 mm in 0.05 mm increments.
PROX
09261555
11 Items

Data sheet

Épaisseur de la pastille de soupape
2,80 mm
Diamètre extérieur
7,48 mm
Marque
PROX
Référence fournisseur
29.748282.5
Nom du produit
Rondelles de calage
Type
Soupape
Unités
Lot de 5
